PTC-UD2J is a Fixed Type or vehicle mounted drone detection and integrated with Jamming functions in one equipment. The equipment adopts an integrated industrial design, with a simple and concealed appearance, strong environmental adaptability, flexible deployment methods, and can be installed and erected in a vehicle or fixed manner.
This device is suitable for low altitude security in scenarios such as large-scale event support, public security patrols, border defense, accompanying protection of political figures, militar-y management zones, power and petrochemical parks, and airports. It can work offline on a single machine, flexibly and quickly deploy, and respond flexibly, meeting the needs of various scenarios.
Product Parameters
| Passive detection | Detectiion Frequencies | 20MHZ-6GHz |
| Detection Rang | 3km |
| Detection Sensitivity | ≥ -95dBm(25kHz) |
| Direction Directivity | 360°Omnidirectional |
| Simultaneous Detection | The Drones in the detecting area |
| Detailed Specification | Support Frequencies | 20MHz to 6GHz full band and customized frequency |
| Detection Height | 0~1000m |
| Detect Drone model | the frequencies between 20-6000mhz and the drones in the detecting area |
| Detection time | ≤2s |
| Refresh time | ≤2s |
| Detection Success rate | ≥99% |
| Working time | 7*24H |
| Working Temperature | -20 to +50ºC |
| Working Time | 7*24H |
| Power supply | AC 110V-240V |
Jamming System Technical Paramter | Channels No. | Frequencies | RF Output Power +/-3dBm |
| 1 | 20-600MHz | 50W |
| 2 | 600-1400MHz | 50W |
| 3 | 1400-2200MHz | 50W |
| 4 | 2200-3000MHz | 50W |
| 5 | 3000-3800MHz | 50W |
| 6 | 3800-4600MHz | 50W |
| 7 | 4600-5400MHz | 50W |
| 8 | 5400-6200MHZ | 50W |
| Total Working Channels | 8-channels |
| Each band power | 50W |
| Total output Power | 400W |
| Power Adjustable | Each band power can be adjustable by software |
| Jamming Range | 500-2000m, the jamming range depends on the local environment
factors and the distance between drone, remote control and Jammer |
| Antenna | Built-in high gain Omni antennas |
| Jamming target | The drone frequencies and remote control frequencies from 20-6000 |
Product Advantages
Product Advantages and Features:
- Each system support Drone signals detecting + Jamming functions.
- Full range of frequencies 20-6000mhz to cover all the drone frequencies.
- Specially equipped with IP65 Waterproof and solid housing for all weather protection.
- Supports Remote control for switching ON/OFF Jammer.
- Supports network management system with remote monitoring platform, equipment status ( abnormally offline and failure alarms status) can be remotely monitored.
- Jammer Failure Alarms: Such as the Jammer opened maliciously, RF cables cut off deliberately, Modules failure,Temperature problems, the failure alarms will be feedback from software.
- UPS backup in case of mains power failure for option.
- ON/OFF each modules separately by computer software.
- Support high power Omni Antennas + Directional Antennas.
- The out-casing with IP65 protection has high resistance to dust, water and corroding.
- Continuous operation, even in hot climates, with no working time limit.
- Smart heat sink designing to make the system in a cooling status.
- Secure design to avoid sabotage.
- (VSWR) circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
- Strong waterproof protection, can be used outdoor all the time
- 2Years Quality Warranty
Installation Instructions
It Can be installed by Fixed Type or Vehicle Installation
Product Application
Any sensitive locations where the drones/UAVs are not allowed to use, like Government, Oilfield, Homeland Security, Large Gathering Place, Counter-terrorism, Ar-my Security, Airport Security, Petrochemical Industry, Sports Venues, VIP Convoy Protection, Schools and Universities
etc.
